Funkwerk elmeg CS410 User Manual

Connecting the audio sockets (Audio in / Audio out)
The telephone isequipped with an input (1) and an output(2) for audio signals. Boththese ports have
a 3.5 mm stereo socket. You can connect the telephone viathese ports to the PC sound card in order to
upload announcements into the phone or save recorded messages on the PC.
Connect the telephone to the PC sound card as shown in figure 3. Use the supplied audio cables (3) for
this purpose.
Telefon Audio in (1) —-> PC, e.g. sound card Line Out (5)
Telephone Audio out (2) —-> PC, e.g. sound card Line In (4)
Please observe the instructionsgivenforthe audio connections of the PC or sound card.
English
3
1
2
3
4
Figure 2

Funkwerk elmeg CS410 Specifications

General

Brand	Funkwerk
Model	elmeg CS410
Category	Telephone
Language	English
