2. PROGRAMMED SCREEN
2-9
Engine The screen for engine.
Pattern 1:
RPM (Analog meter for En-
gine Revolutions Per
Minute),
SOG (Speed Over the
Ground),
COG (Course Over the
Ground)
Pattern 2:
RPM (Analog meter for En-
gine Revolutions Per
Minute),
Boost (Analog meter for en-
gine boost pressure),
E Temp (Analog meter for
engine temperature),
Volts (Analog meter for in-
put voltage)
Pattern 3:
RPM (Engine Revolutions
Per Minute),
Oil P (Engine oil pressure),
Boost (Engine boost pres-
sure),
Oil (Engine oil temperature)
Pattern 4:
RPM (Engine Revolutions
Per Minute),
Oil P (Engine oil pressure),
Oil (Engine oil tempera-
ture),
Boost (Engine boost pres-
sure),
Coolant (Engine coolant
pressure),
Volts (Input voltage)
Menu item Description Screen
Pattern 1
Pattern 2
Pattern 3
Pattern 4
