AILEVATOR
[Corresponding model type]: Airplane/glider, Ailevator
(Effective only when 2 servos used at the elevators)
This function improves the performance of the roll
axis by operating the elevators as ailerons.
Ailevator is where each elevator in a standard
(conventional) or v-tail moves independently, like
ailerons on a wing. In addition to each elevator side
moving up and down together, each side moves in
opposite directions when moving as an Ailevator. On
a V-tail, this is also known as a Ruddervator, as they
can serve the same purpose. Typically, both Ailevator
and ailerons are coupled together to maximize roll
performance, especially on larger wingspan planes.
Note: Select Ailevator as the Model Type at the Model
Type screen. This changes the output channel. Check
the Function menu.
(Aileron function)
● When the elevators are used
as ailerons, aileron travel of
the left and right elevators
can be adjusted.
(Elevator function)
● The up and down rate of both
elevators when the elevator stick
is mo ved ca n b e ind i v i duall y
adjusted.
●Select[AILEVATOR] at theModelmenu
and access the setup screen shown
below by touching the RTN button.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
Setting method
● Travel adjustment
Move the cursor to the item you want to
adjust and touch the RTN button to switch to
the data input mode.
Adjust the rate by scrolling the touch sensor.
Initialvalue:ELE:+100%,AIL:0%
Adjustmentrange:-120~+120%
*When the RTN button is touched for one second, the rate is
reset to the initial value.)
Touch the RTN button to return to the cursor
mode.
*If the mixing direction is reversed, adjustments can be made
by changing the mixing rate polarity (+ or -).
*If a large value of travel is specified, when the sticks are
moved at the same time, the controls may bind or run out of
travel. Decrease the travel until no binding occurs.
To Next Page
