<Model Menu (Airplane/Glider Functions)>
●Selectthefunction name
and return to the Model
menu by touching the
RTN button.
<SensorTouch™>
CAMBER MIX
[Corresponding model type]: Airplane/glider, 2 ailerons or more
This function adjusts the rate of camber
operation for the wing camber (ailerons, camber
flaps, brake flaps) in the negative and positive
directions. The aileron, flap, and elevator rates
can also be adjusted independently and attitude
changes caused by camber operation can be
corrected.
*Initial setting assigns camber operation to side lever LS.
● The up/down sideratesof the aileron,flap,and
elevator servos can be adjusted. When the mixing
direction is reversed by the linkage, adjustments
can be made by changing the mixing rate
polarity (+ or -).
● Mixing during flight can be turned ON/OFF by
setting a switch. (Always ON at [--] setting)
●Aconditiondelaycanbeset.Acutswitchwhich
can turn OFF the delay function can be set.
●Conditiondelay
cut switch
●Conditiondelay
setting
●Aileronrate
adjustment
(Glider: Currently selected
condition name)
● Select[CAMBER MIX] at theModel
menu and access the setup screen
shown below by touching the RTN
button.
*The display screen is an example. The actual
screen depends on the model type.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
●Flaprate
adjustment
●Elevatorrate
adjustment
