FUTABA 8FG - AIL Differential (Except 1-AIL)

82
<Model Menu (Airplane/Glider Functions)>
●Selectthefunction name
and return to the Model
menu by touching the
RTN button.
<SensorTouch™>
AIL 3
(Chip Aileron)
AIL 4
(Chip Aileron)
AIL1
(Main Aileron)
AIL 2
(Main Aileron)
AIL DIFF.
[Corresponding model type]: Airplane/glider, 2 ailerons or more
The left and right aileron differential can be
adjusted independently.
For glider, the differential rate in buttery mixing
can be adjusted.
*The display screen is an example. The actual
screen depends on the Model Type.
Setting method
●Aileron left/right adjustment
Move the cursor to the aileron (AIL) 1~4 left (or
right) setting item and touch the RTN button
to switch to the data input mode.
Adjust the aileron angles by scrolling the
touch sensor when the stick is moved to the
left (or right) end.
 Initialvalue:100%
 Adjustmentrange:0~120%
*When the RTN button is touched for one second, the rate is
reset to the initial value.)
Touch the RTN button to end the adjustment
and return to the cursor mode.
●Aileron differential adjustment in buttery
mixing
Move the cursor to the [BUTTERFLY ADJUST]
item and touch the RTN button to switch to
the data input mode.
(Currently selected condition name)
● Select [AIL DIFF.]at the Model menu
and access the setup screen shown
below by touching the RTN button.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
[Airplane (2A+2F)]
[Glider (4A+2F)]
●Aileronleft/right
adjustment
Adjust the differential rate by scrolling the
touch sensor.
 Initialvalue:0%
 Adjustmentrange:-120~+120%
*When the RTN button is touched for one second, the rate is
reset to the initial value.)
Touch the RTN button to end the adjustment
and return to the cursor mode.
