<Functions of Model Menu (Helicopter Functions)>
●Selectthefunction name
and return to the Model
menu by touching the
RTN button.
<SensorTouch™>
MODEL MENU (HELICOPTER)
This section contains information on the
commands that apply to helicopters only. For
instructions on Airplanes and Sailplanes, refer to
the sections pertaining to those aircraft.
Use the Model Type function in the Linkage
Menu to select the swash type matched to the
respective aircraft.
Also, activate/deactivate flight conditions
according to your model. To do so, access at the
Condition Select screen prior to adjusting the
model's parameters. (Up to ve conditions can be
used)
The Dual Rate function and other functions
common to all model types have already been
described elsewhere in this manual. Please refer to
these respective sections for information on how to
do so.
Model Menu functions (helicopter) list
PIT CURVE: Adjusts pitch settings in different ight conditions
THR CURVE: Throttle curve and hovering trim adjustment in different ight conditions
THR HOLD: Moves the throttle to idle during autorotation
SWASH MIX: Compensates control response in different ight conditions
THROTTLE MIX: Compensates for power loss when cyclic applied
PIT to NEEDLE: Adjusts pitch response in different ight conditions
PIT to RUD: Compensates torque changes from pitch angle inputs
GYRO: Used to switch gyro sensitivity
GOVERNOR: Used to switch RPM of the helicopter’s head
● Access the Model menu shown below by
touching the RTN button twice at the home
screen, etc.
Scrolling
●Movingcursor
●Tonextpage
● Select the function you
want to set and access
t h e s e t u p s c r e e n b y
touching the RTN button.
