FUTABA 8FG - Throttle Cut (Air;Heli Only)

62
<Functions of Linkage Menu>
●Selectthefunction name
and return to the Linkage
menu by touching the
RTN button.
<SensorTouch™>
THR CUT
Stops the engine safely and easily.(airplane and helicopter only)
Throttle cut provides an easy way to stop the
engine. Generally speaking, modelers will do so
by ipping a switch with the throttle stick at idle.
The action is not functional at high throttle to
avoid accidental dead stick landings. The switch’s
location and direction must be chosen, as it defaults
to NULL.
Throttle cut setting procedure
1. Activate the function:
Move the cursor to the [ACT] item and touch
the RTN button to switch to the data input
mode.
Select the ACT mode by scrolling the touch
sensor.
*The display blinks.
Tou ch the RTN butto n t o a ctiva te the
function and return to the cursor mode.
2. Switch selection:
Move the cursor to the [SW] item and access
the switch setup screen by touching the
RTN button and select the switch and ON
direction.
*For a detailed description of the setting method, see [Switch
Setting Method] at the back of this manual.
3. Throttle cut position setting:
Move the cursor to the [POS] item and touch
the RTN button to switch to the data input
mode.
Adjust the servo operation position at throttle
cut operation by scrolling the touch sensor.
 Initialvalue:17%
 Adjustmentrange:0%~50%
*When the RTN button is touched for one second, the servo
operation position is reset to the initial value.)
Touch the RTN button to end the adjustment
and return to the cursor mode.
*With the selected cut switch ON and the throttle stick at idle;
adjust the rate until the engine consistently cuts off.
However, be sure that the throttle linkage is not pulled too
tight or unreasonable force is not applied to the servo.
●Select[THRCUT]intheLinkagemenuandaccess
the setup screen shown below by touching the
RTN button.
●Currentthrottleposition ●Cutposition
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
