System Section
SYSTEM
MENU
The following controls and menus are used for system-wide settings.
These are settings that are stored for, or may be used for any and all
of the different model setups stored in the PCM 1024Z's memory.
To select any of these keys, first select the horizontal line contain-
ing the item you wish to select, using the B or C keys adjacent to
the
left-hand
side
of
the
screen.
Then,
select
the
desired
item
with
the
F to L keys underneath the display.
Select Line With
These Keys
To Home Screen
To Model Menu
To Condition Menu
Function Selection Keys
Listed below are the contents of the System Settings Menu:
System Menu Contents
Item_______Definition____________
Function
Page
MSL
.
.
.Model
Selection
........
.Use
to
load desired model's
.....
25
settings
VLT.
.
.
.Voltmeter
...........
.Use
adjustable load
to
........
26
check batteries
TAC.
. .
.Tachometer
..........
.Measures
propeller
rotational
....
27
speed
SRV
.
.
.Servo
Test & Bar
.......
.Displays
servo
positions
.......
28
Graph Display and cycles
TRN
.
.
.Trainer System
........
.Sets
desired
instructional.
......
29
channels
DTN . . .Data Transfer Function . . . .Copies model data to another.... 30
1024Z
CPM . . .Copy Model Function .... .Copies a setup into a second. .... 31
memory
CPC. . . .Copy Condition Function . . .Copies a single condition to ..... 32
another
PAR.
. .
.Parameters.
..........
.Sets
Auto-Off and
Screen
......
33
Contrast
UNA . . .User Name Registration . . . .Set up your name & security .... 34
code
FRQ . . .Transmitter Frequency. . . . .1024ZAPS/HPS Synthesized .... 35
Setting systems only (See CAUTION
message)
Setting The Frequency Synthesizer. . . .Choosing the desired frequency . . . 36
Receiver
SWT
. .
.Switch
Setting.
........
.Use
to
define switch
to.
.......
37
activate functions
System Section, Page 24
