Model Setting Section
CH9—CHANNEL 9 SWITCH DEFINITION
Your PCM 1024Z system has nine channels.
The ninth channel is a switch channel, and the
location of the switch may be selected with this
menu. The default switch is SW(B), with its ON
position at Position 2.
CH9 Switch Selection
In the Model Menu, press the CH9 key to get the
Channel 9 Switch Selection menu. This will put the switch
display onto the screen. The Factory-Default CH9 Switch
Position is Switch B, Turning On at Position 2
ON
SW(B)
ON/OFF Setting
Keys
• Return to Model
Menu
Switch Selection Keys (NUL cancels input)
Choose the desired switch location with the A to
H
keys. NUL (I) clears the set switch.
CH9 Switch On/Off Direction Definition
To
select
the ON/OFF direction,
press
the P and R
left-arrow keys. On and off are toggled with each press of
the button.
Exit this function by pressing the
END (N
) key.
Model Setting Section, Page 50
To Next Page
