161
<Data>
Switch selection
When the switch selection button in switch mode selection screen or the logic switch setting screen is
touched, the screen below is shown.
(Switch selection screen example)
When switch is selected
Switch ON/OFF setting is possible at each
position.
Alternate:
available depending on mixing function.
the switch was selected, the screen shown
below appears.
*When the button of each position is touched,
When stick, trim lever, or VR is selected.
When a stick, trim lever, or VR is used as a
switch, the following 4 modes can be selected.
Mode: Lin/Sym
Type: Hysteresis (Hys.)/box (Box)
stick, etc. was selected, the screen shown
below appears.
2. Select the mode you want to use, and set it
as described below.
