＜ BeforeUse ＞
ũƈƄƗƘƕƈƖŃ
FASSTest system
The T18SZ transmitter has adopted the bidirectional communication system "FASSTest"
.
Data from the
receiver can be checked in your transmitter. FASSTest is a maximum 18 channels (linear 16 channels +
switch 2 channels) 2.4GHz dedicated system.
Color touch screen LCD
T18SZ has a HVGA 4.3inch full color Backlight LCD touch screen. The screen is manufactured of a
WUDQVÀHFWLYHFRQVWUXFWLRQZKLFKHQDEOHVERWKLQGRRUDQGRXWGRRUYLVLELOLW\
S.BUS2 system
By using the S.BUS2 system multiple servos, gyros and telemetry sensors are easily installed with a
minimum amount of cables.
Model types
Multicopter. 8 swash types are available for helicopters. 7 types of main wings and 3 types of tail wings
are available for airplanes and gliders. Functions and mixing functions necessary for each model type are
set in advance at the factory.
LiFe battery
T18SZ is operated by a 6.6 V/2,100 mAh Lithium Ferrite battery.
SD card (Secure Digital memory card) (Not included)
Model data can be saved to an SD card (SD:32MB-2GB SDHC:4GB-32GB). When T18SZ transmitter
VRIWZDUH¿OHVDUHUHOHDVHGWKHVRIWZDUHFDQEHXSGDWHGE\XVLQJDQ6'FDUGXSGDWH
Edit button
Two edit buttons are provided, and the operating screen can be immediately “Returned” to the HOME
screen during operation. Setting operation can be performed easily by combining this button with a touch
sensor.
Vibration function
Selects a function that alerts the operator to various alarms by vibrating the transmitter in addition to
sounding a buzzer.
Speech function
A function is equipped which allows the system to provide telemetry data audibly. This function can
also be utilized with commercially available earphones.
BEFORE USE

FUTABA T18SZ Specifications

General

Channels	18
Frequency	2.4GHz
Telemetry	Yes
Modulation	FASSTest, FASST, S-FHSS, T-FHSS
Display	Color LCD
Model Memory	30
