FUTABA T18SZ User Manual

91
＜ Linkagemenu ＞
Viewingthetelemetrydata
Telemetrysystem
＜ Homedisplay ＞
Receivervoltageand
Extvoltagedisplay
7KLVVFUHHQGLVSOD\VDQGVHWVWKHYDULRXVLQIRUPDWLRQIURPWKHUHFHLYHU$QDODUPDQGYLEUDWLRQFDQEH
JHQHUDWHGGHSHQGLQJRQWKHLQIRUPDWLRQ)RUH[DPSOHDGURSLQWKHYROWDJHRIWKHUHFHLYHUEDWWHU\KRXVHG
LQWKHDLUFUDIWFDQEHUHSRUWHGE\DQDODUP
● ThisfunctioncanonlybeusedintheFASSTest18CHmodeandT-FHSSmode.TheFASST/S-FHSSmodecannotuse
telemetry.
● FASSTest12CHmode.Applicablewithreceivervoltagedisplay.
● Telemetrysensorssoldseparatelycanbemountedintheaircrafttodisplayavarietyofinformation.(Receivervoltage
doesnotrequireasensor.)
● ThetelemetryfunctioncannotbeusedifthetelemetrymodeoftheparametersisnotACT.
● T-FHSS:When2receiversareusedwith1transmitter,thetelemetryfunctioncannotbeused.
● Ifthetransmitterandreceiverarelinked,butthereceiver'sIDisnotrecordedinthetransmitter'smemory,thetelemetry
functioncannotbeused.
● TurningOFFthereceiverafterusewillcausethetelemetrydatajustpriortothistobedisplayed.(Evenwhenthe
receiver'dpoweristurnedOFF,thereceivervoltageisnot0.0V.)
Viewingthereceivervoltage. Settingisunnecessary.Whenmenutelemetryis
listenedto,thevoltageappears.
Viewingthedrivebattery
voltage.
CA-RVIN-700andwiringworkarenecessary.
Usingvariousoptional
telemetrysensors.
Optionaltelemetrysensorsarenecessary.
T18SZsettingisunnecessary.
Usingseveraltelemetry
sensorsofthesametype.
Settingby"sensor"inthemenuisnecessary.
(Registerisnecessary.)
Settingalarmsfromthe
telemetryinformation.
Settingby"Telemetry"inthemenuisnecessary.
P.91
P.98
P.92
P.94
P.96 〜 111
CAUTION
Donotstareatorsetthetransmitter
settingscreenwhileflying.
■ Losingsightoftheaircraftduringflightisvery
dangerous.
■ Whenyouwanttochecktheinformationduring
flight,callthetelemetryscreenbeforeflightand
havethescreencheckedbysomeoneotherthan
theoperator.
Receiver →Transmitter.Thereceptionofthesignal
fromthereceivertothetransmitterisshown.This
doesnotaffectflight.
