< Linkagemenu >
T1-T6setting(Trim)
Digital trim settings
7KLVIXQFWLRQDGMXVWVWKHGLJLWDOWULPVFRQWURO
VWHSDPRXQWDQGRSHUDWLRQPRGH77
Control step amount setting
1. The [Step] item tap the screen to the data
input mode.
Set the control step amount by tapping the
"
▲▲
" "
▲
"
"
▼▼
" "
▼
" button.
Initial value: 4
Adjustment range: 1~200
(When the value is tapped, the control step
amount is reset to the initial value.)
:KHQWKHYDOXHLVPDGHODUJHWKHFKDQJHSHUVWHSEHFRPHV
ODUJHU
Separate/combination mode selection
[Comb.]: Combination mode. The trim data
are reÁected at all the Áight conditions.
[Separ.]: Separate mode. Trim adjustment for
each Áight condition.
ŏ Select [T1-T6 setting] at the linkage menu and call
the setup screen shown below.
:KHQWKHIOLJKWFRQGLWLRQVDUHVHWWKHWULP
RSHUDWLRQFDQEHFRXSOHGZLWKDPRQJDOOWKH
FRQGLWLRQVZKLFKFRPELQDWLRQPRGHLVVHOHFWHG
ŏReturn to Linkage
menu
