FUTABA T18SZ - Page 111

111
＜ Linkagemenu ＞
Tappingthiswill
takeyoutothe
settingsscreenfor
thecurrentalarm
Telemetry:Current[Current][Voltage][Capacity]
7KH6%6&KDVWKHFDSDELOLW\RIPHDVXULQJ
FXUUHQWYROWDJHDQGFDSDFLW\FRQVXPSWLRQIURP
GULYHEDWWHU\DWWKHVDPHWLPH
*Currentsensormustbeinstalledinthe
aircraft.
ŏ Select [Current] in the Telemetry screen
and access the setup screen shown below.
Max.andmin.values
sincethepower
wasturnedONwill
display.
Asetupofthe
currentonwhichthe
alarmoperates.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
TheON/OFFswitch
ofSpeechischosen.
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesbelow
yoursetvalue.
Initialvalue:↑ 100A↓ 0A
Adjustmentrange0A~150A
( ↑ Limit≧↓ Limit)
ŏReturn to Linkage menu
*Refer to the manual of SBS-01C for the details of wiring.
Current
Voltage
Consumptioncapacity
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
