139
＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
Setting method
ŏ Tap [INH].
(ON is displayed.)
ŏ When setting a switch, tap to the [--] item
of the switch and tap the screen to call the
selection screen. Then, select the switch and
set its ON direction. (Always ON at "--" setting)
(For a description of the switch selection
method, see the description at the back of
this manual.)
ŏ When setting a VR, tap the Fine tuning
"--" item and tap the screen to call the
selection screen and then select the VR. The
adjustment rate can be set.
The VR operation mode can also be set.
(For a description of the Àne tuning VR setting
method, see the description at the back of
this manual.)
ŏ A mixing curve can be set.
(For a description of the curve setting
method, see the description at the back of
this manual.)
ŏ When linking: tap the [Link] item. (ON is
displayed.)
Currentlyselectedconditionname
● Mixingcurvesetting
(Foradescriptionofthe
settingmethod,seethe
descriptionattheback
ofthismanual.)
Up/Downoverall
adjustmentatRateA
andRateB
Activatethefunctionby
tappingthe[INH].
Conditiongroup/single
modeselection(Gr./Sngl)
TheON/OFFswitchof
mixingischosen.
Finetuning
setting
Tosetlinking,tapto
the[OFF]item
Rudder → Elevator
[Corresponding model type]: Airplane, general
This function is used when you want to mix
elevator operation with rudder operation. It is used
to correct undesirable tendencies when rudder
is applied in roll maneuvers, knife edge, etc. of
acrobatic planes.
ŏ A mixing curve can be set.
ŏ Mixing during Áight can be turned ON/OFF by
setting a switch. (Always ON at [--] setting)
ŏ Link can be set: Links this mixing to other mixings.
ŏ The mixing rate can be Àne-tuned by setting a VR.
(Fine tuning)
ŏ Select [RudderńElevator] at the
model menu and call the setup
screen shown below.
