＜ ModelMenu(HelicopterFunctions) ＞
ųƌƗƆƋŃƗƕƌƐŃŋūƒƙƈƕƌƑƊŃƓƌƗƆƋŏŃƋƌƊƋŃƓƌƗƆƋŏŃƏƒƚŃƓƌƗƆƋŌ
The hovering pitch, low pitch, and high pitch trim setup screen can be called from the Pitch curve setup
screen.
Hoveringpitchtrim
setting
Low/highpitchtrim
setting
Hovering pitch trim
The Hovering Pitch trim function trims the pitch
near the hovering point. Normally, it is used with
the hovering condition. The hovering pitch can be
¿QHWXQHGIRUFKDQJHVLQURWRUVSHHGDFFRPSDQ\LQJ
FKDQJHVLQWHPSHUDWXUHKXPLGLW\DQGRWKHUÀLJKW
conditions. Adjust the hovering pitch so that
rotor speed is constant. This function can be used
together with the hovering Throttle Trim function
for more delicate operation.
Setting method
ŏ When using only the hovering (normal)
condition, switch the group mode to the
single mode (initial setting) before setting.
ŏ Tap [INH]. (ON is displayed.)
ŏ Select the adjustment knob.
Selection example: LD
ŏ The trim operation mode (Mode: Center/
Normal) can be selected.
Center mode: Maximum amount of change
near center by center trim operation
(recommended)
Normal mode: Normal trim (parallel
movement trim) operation. The advantage
of using this mode is that the hovering pitch
can be adjusted without changing the
curve.
ŏ Trim adjustment range (Range) setting
When this value is made small, trim can only
be used near the center.
ŏ The trim rate can be adjusted and the
operation direction can be changed.
High Pitch/Low Pitch Trim
High Pitch/Low Pitch Trim is the pitch servo
high side and low side trim function.
Setting method
ŏ When setting the adjustment knobs common
to all the conditions, set them in the group
mode.
ŏ Tap [INH]. (ON is displayed.)
ŏ Select the adjustment knobs.
Selection example: LS (high side), RS (low
side)
ŏ The trim rate can be adjusted and the
operation direction can be changed.
ŏ Trim acts as high side or low side trim with the
center as the standard.
