165
＜ ModelMenu(HelicopterFunctions) ＞
＊ Gyrogainchannel
Gyro:CH5
FortheFASSTest12CH,Gyro/RUDis6ch.Thegyrosensitivityadjustmentconnectorconnectsto6ch.
＊ Gyrogainchannel
GyroRUD:CH5
FortheFASSTest12CH,Gyro/RUDis6ch.
Gyro2AIL:CH9
Gyro3ELE:CH10 FortheCGY750,simplyconnecttheS.BUS;functionsdonotneedtobeset.
(FortheFASSTest12CH,changeGyron/RUDto6ch.)
Usageexample#1:Usinggyroforonlytherudderandadjustingsensitivityforeachcondition
Usageexample#2:Using3-axisgyroCGY750andadjustingsensitivityforeachcondition
Becausesensitivitychangesfor
hoveringandidleup,perform
switchoverforeachconditionand
adjustsensitivity.
Becausesensitivitychangesfor
hoveringandidleup,perform
switchoverforeachconditionand
adjustsensitivity.
Becausethe
sensitivityisswitched
(Sngl)percondition,
Rate2andRate3are
notused.
Becausethe
sensitivityisswitched
(Sngl)percondition,
Rate2andRate3are
notused.
Tappingherewilllet
youselecteitherNormal
orAVCSforeachofthe
threeaxes.
Thisisallthatisneeded
foruseinthiscase.
Thisisallthatisneeded
foruseinthiscase.
Tappingherewillletyou
selecteitherNormalor
AVCS.
Setgainofarudder
Setgainofarudder Setgainofaaileron
Setgainofaelevator
ŏ Select [Gyro] at the
model menu and call
the setup screen.
ŏ Select [Gyro] at the
model menu and call
the setup screen.
