FUTABA T18SZ - Page 167

167
＜ ModelMenu(HelicopterFunctions) ＞
Ɣ'LSOD\PRGHVHOHFWLRQ
*When [rpm] mode is selected above setting, the display
mode can be selected.
* There is no change in the transmitter output even when the
"Mode" is changed. Calibration should be performed via the
governor.
* In order to use the Governor function of the T18SZ, it is
necessary to change the settings on the governor for the low
side 700 rpm mode.
When the Mode of the Governor screen's
model menu is changed, the change is also
indicated on-screen.
Thechartbelowindicatesthe
modepercentageandthe
correspondingRPM.
mainrotorR.P.M.
3900rpm
2700rpm
2100rpm
0% 100% 110%
mainrotorR.P.M.settingchanneltravel
50%:neutral
2500rpm
2000rpm
1500rpm
1000rpm
700rpm
3500rpm
Ɣ)LQHWXQLQJ95VHWWLQJV
Tap to the [--] item and tap the screen to
access the selection screen. Select the
control.
*For a description of the switch selection method, see the
description at the back of this manual.
Tap to the rate item .
Adjust the trim rate by "ʈʈ" "ʈ" "ʆ" "ʆʆ"
button.
Initial value: 0 (0rpm)
Adjustment range: -20~+20
*When the screen is tapped for one second, the sensitivity is
reset to the initial value.
Tap the screen to return to the cursor mode.
