＜ Data ＞
*[Separ.] mode: Normal setting
*[Comb.] mode: Creates a left and right
symmetrical curve.
Line and spline curve adjustment
Line curves or spline curves of up to
11/17 points can be used. (Initial value: 11/9
points) The set points can be freely increased,
decreased, and offset. Curves which are
symmetrical to the left and right of center can
also be set.
[Adjusting the rate of each point]
1. Use the move between points buttons [
←
] or [
→
] to select the point. (The red
point is the selected point.)
2. Tap the Rate button.
3. Use the "ʈʈ" "ʈ" "ʆ" "ʆʆ" buttons to
adjust the rate.
[Point addition method]
1. Tap the "Position" button.
2.
Tap the "ʈʈ" "ʈ" "ʆ" "ʆʆ" button and
select to the position (mark
) you want to
add.
3. When the "Add" is tapped, the point is
added.
*A new point is created.
[Point deletion]
1. Use the move between points button [
←
] or [
→
] and select the point. (The red
point is the selected point.)
2. Tap the [Remove] button. (The selected
point becomes an outlined point.)
3. Tap the move between point button [
←
]
or [
→
].
*The point is deleted.
The curve can also be offset horizontally in
the vertical direction.
[Offsetting the curve horizontally in the
vertical direction]
1. Tap the Offset button.
2. Use the "ʈʈ" "ʈ" "ʆ" "ʆʆ" buttons to
move the curve horizontally up and
down.
*Initial value: +0.0
*The mark on the curve
shows the currently selected
point.
