＜ BasicOperation ＞
*If there are many FASSTest (T-FHSS) systems
turned on around your receiver, it might not
link to your transmitter. In this case, even if the
receiver's LED stays solid green, unfortunately
the receiver might have established a link
to one of other transmitters. This is very
dangerous if you do not notice this situation.
In order to avoid the problem, we strongly
recommend you to double check whether
your receiver is really under control by your
transmitter by giving the stick input and then
checking the servo response.
*Do not perform the linking operation when
the drive motor is connected or the engine is
running.
*When you use two receivers, please be sure to
10. When a telemetry function is enabled,
the receiving interval (down-link interval)
of sensor data can be changed. If a D/
L interval is increased, the response of the
sensor data display becomes slower, but
stick response will improve.
Initial value: 1.0s
Adjustment range: 0.1s~2.0s
9. ACT will be chosen if telemetry is used.
It is INH when not using it.
Aftersetting,pressaHOME/EXITbutton
setup a "Rx1" and "Rx2" in the "dual" mode.
*Telemetry function cannot be used for the 2nd
receiver.
→
FASSTest18CH
*Telemetry function cannot be used for the dual
mode.
→
T-FHSS
*You must link one receiver at a time. If both
power supplies to the receivers are switched on
simultaneously, data is received incorrectly by
the transmitter.
*You cannot link three receivers.
*Link is required when a system type is
changed.
*Linking is required whenever a new model is
made.
WARNING
Afterthelinkingisdone,pleasecycle
receiverpowerandcheckthatthe
receivertobelinkedisreallyunderthe
controlofthetransmitter.
Donotperformthelinkingprocedure
withmotor'smainwireconnectedor
withtheengineoperatingasitmay
resultinseriousinjury.
