Futurecom VR - Page 83

8G093X01 R5
VR Programming Guide
August 2022 Page 83 of 144
Field Name
Range
Description
Notes
Steer. NAC
0 to FFF
Hex
Hex number used for
remote change of MSU
TG / channel. Must
match the NAC
programmed in the
PSU.
Refer to the “Remote VR Activation and Steering
by PSU Call Alert (Page)” section in VR
Functional Description doc
VR Ch
number
If Rptr Independent
Channel Change is
Disabled, this field
determines which VR
Channel will be
automatically selected
upon selection of the
specified Mobile Radio
Mode (TG or Channel).
The Rptr Independent Channel Change Field is
found in the VR Common Setup window.
Refer to Table 4 - Field Interactions Determining
VR Mode on Power Up
TG Mode
None
Local
System
User
Disabled
OFF
Enables or Disables
Slaving of the VR
Mode to the selected
TG.
‘None’ → this selection
assumes no specific
VR Mode is linked to
the TG. The VR stays
in the last mode or the
Mode associated with
the VR Channel.
‘Local’ / ‘System’ →
This selection forces
the VR Mode to
change to either Local
or System respectively
upon selection of the
TG.
‘User’ → The Last VR
Mode that was
selected by the User is
in effect and the User
can change it as
required.
‘Disabled’ → VR is
Disabled when this TG
is selected.
‘OFF’ → VR is in OFF
mode when this TG is
selected.
The ‘Disabled’ setting must be selected in case of
multi frequency band MSU modes (trunked or
conventional) when band locking is enabled (i.e.,
no in-band filters are installed).
In such case, if a different TG Mode is selected, the
Futurecom Repeater Configurator TG Mode field
will be red, and the personality can’t be saved in
the VR.
Manual
Mode Chg.
Enabled
Disabled
Enables or Disables
the Mode change (SYS
/ LOC) via the VRS
button when a specific
TG is selected.
