5.4.4 Video Tuning Settings
After you access IVT, the following settings are available to you in the open IVT
submenu:
 Establishing the video boost.
 Setting the noise filter.
 Fine tuning.
 Delay setting (optional) on the colors R, G, and B of the CAT-x cable.
The IVT submenu appears as follows:
IVT
Active channel: 1
CVM
Boost 4
Noise filter 0
Fine tuning 36
delay R delay G delay B
0 ns 0 ns 0 ns
ESC: quit IVT menu
F1: save and quit
F3: copy to all channels
1/2/3/4: select channel
F5: auto adjust active channel
F6: auto adjust all channels
ESC: Exits the IVT submenu without saving changes
F1: Saves all changes and closes the IVT submenu
F3: copies all settings to all channels
1/2/3/4 Selecting the video channel (only with CATVision-MC-
Systemen)
F5: Carries out automatic video optimization for the active channel
F6: Carries out automatic video optimization for all channels
You can switch between the individual entries using the UP ARROW and/or
DOWN ARROW keys.
The position of IVT-menu can be placed individual on your monitor with the
HotKey-combination SHIFT+ Cursor.
