7.3 Cutting Plotter/Computer Communication Problems
The messages showed below present problems in relation to cutting plotter/computer
communication.
Communication Error
Setup: MISC. key
Is the connection cable
connected to the cutting plotter
and computer properly?
Yes
No
Has the interface setting
been done correctly?
Refer to Chapter 2 -
Connecting your cutting
plotter.
Yes
No
Try the communication
between your cutting plotter
and computer. If it still does
not work, have your cutting
plotter serviced.
Refer to the “MISC” key in
Chapter 3 - Description of
Operation for the port setup.
If your cutting plotter cannot recognize the
HP-GL/2 or HP-GL commands, please
check the HP-GL/2 or HP-GL commands
applied to your cutting plotter are used
properly.
Note:
The computer also needs to set up compatible communication
parameters to the cutting plotter set up.
HP-GL/2 Cmd. Error
