2.4.2 Blade Holder Installation
Step 1 Loosen thumb screw and insert the blade holder into extension holder
Step 2 Fasten the thumb screw to fix the tool carriage.
Step 3 The machine is ready to use.
Step 4 Use the reversing steps to remove the blade holder.
