GCC Technologies AFR-24S - Menu Navigation: Off-line Mode

AFR-24S User Manual
65
Blade Length Adjust
Select: OK:ENTER
Set Length 0.00mm
Change: OK: ENTER
Test Blade Holder
OK: ENTER
Test Blade Length
OK: ENTER
Turn CW O Turn
N:ONLINE OK: ENTER
Adjustment completes
OK: ENTER
Ratio: 100%, 200%, 300%, 400%
Ratio Setting
Select: OK:ENTER
Pattern: Cross, Arrow
Pattern Setting
Select: OK:ENTER
Ratio: 100%
Change: OK: ENTER
Pattern: Arrow
Change: OK: ENTER
Cut off Type
Select: OK:ENTER
Auto Cut Off System
Select: OK:ENTER
Blade Holder Cut Off
Select: OK:ENTER
Force: 200g
Speed: 40mm/s
3.3 Menu in Off-line Mode
C Speed: 3~153 with an increment of 3 (cm/s)
[CUT TEST ]
C Force:80 gf
OK:ENTER
Offline For System Setup
Square Cut
Select: OK:ENTER
Repeat AAS Job
Select: OK:ENTER
Redo Jobs in Memory
Select: OK:ENTER
Recut #1
Select: OK:ENTER
Copy #1
Select: OK:ENTER
Recut number: 0-99
Copy number: 1-999
move origin M
X: Y:
[
]
Draft, Fair, Normal, Fine, Small Letter
[ SPEED ]
Draft, Fair, Normal, Fine, Small Letter
C Speed: 72 cm/s
Select: OK:ENTER
UP Speed: 3~153 with an increment of 3 (cm/s)
P Speed: 72 cm/s
Select: OK:ENTER
P Speed: 3~153 with an increment of 3 (cm/s)
UP Speed: 72 cm/s
Select: OK:ENTER
C Quality: Normal
Select: OK:ENTER
P Quality: Medium
Select: OK:ENTER
[ FORCE]
5~600 with an increment of 5 (gram force)
P Force:80 gf
OK:ENTER
5~600 with an increment of 5 (gram force)
[ DATA CLEAR ]
Clear Data Memory
N:ONLINE OK:ENTER
[ OFFSET ]
Offset: 0.275 mm
OK:ENTER
0.000~1.000 with an increment of 0.025 (mm)
Cutting off Paper
N:ONLINE OK:ENTER
AAS Speed: Medium
Select: OK: ENTER
High, Medium, Low
[CUT OFF ]
