GCC Technologies AFR-24S - Loading Media Manually

AFR-24S User Manual
81
4.2 How To Load The Sheet Media Into Machine Without Auto
Feeder
To load the media properly, please follow the procedures listed below:
Step 1
Use the lever on the upper right side of the cutting plotter to raise or lower down pinch rollers.
Pull the lever forward until it makes a clicking sound then the pinch rollers are raised (Figure
4-1).
Lever
Figure 4-1
V
