AFR-24S User Manual
4.6.2 RX II-Creasing Print Driver setting > Creasing Page
The RX II series incorporates the use of 16 different colors to represent 16 different
parameter settings including cutting speed, force and blade offset settings when cutting.
These colors are referred to as “Tools”. Think of each color as a designated cutter setting,
rather than as a color. An image that is made up of black, red and blue colors will be
processed using the cutter settings designated for each particular color. In order to utilize up
to 16 different colors (cutter parameter settings), make sure your graphics software can
recognize and utilizes the 16 colors designated by the GCC RX II series print driver (please
refer to figure 4-21).
