GCC Technologies AFR-24S - Page 4

AFR-24S User Manual
4
4.1.1 Automatic Working Procedure
4.1.2 Back Creasing
4.2 How To Load The Sheet Media Into Machine Without Auto Feeder
4.3 Cutting Force And Offset Adjustment
78
80
81
84
4.4 How To Cut 3mm Letter
86
4.5 When Completing The Cutting Job
86
4.6 RX II-Creasing Print Driver Setting
87
4.6.1 RXII-Creasing Print Driver setting > Option Page
87
4.6.2 RXII-Creasing Print Driver setting > Creasing Page
4.6.3 RXII-Creasing Print Driver setting > Paper Page
4.6.4 RXII-Creasing Print Driver setting > Paper Feeder Page
4.7 Reference Parameter Setting for Different Materials
91
98
99
100
5. Automatic-Aligning System
5.1 Introduction
101
5.2 AAS Contour Cutting System
102
5.2.1 Notice for Registration Marks
102
5.2.2 AAS II On RX II
103
5.2.3 Automatic Distinction Of The Plot Direction
105
5.3 Printer Test
106
5.4 Registration Mark Offset Range
5.5 Contour Cutting
5.6 Tips For AAS
108
108
110
6. Maintenance
6.1 Cleaning The Cutting Plotter
111
6.2 Cleaning The Grid Drum
112
6.3 Cleaning The Pinch Rollers
112
7. Trouble Shooting
7.1 Non-Operational Problems
113
7.2 Operational Problems
114
7.3 Cutting Plotter/Computer Communication Problems
115
7.4 Software Problems
116
7.5 Cutting Quality Problem
117
Appendix
A-1 AFR-24S Specification
A-1
A-2 Blade Specification
A-2
A-3 CorelDraw
A-3
A-4 CorelDRAW Plug-in
A-4
A-5 Illustrator Plug-In
A-5
A-6 GreatCut Plug-In
A-6
A-7 SignPal 12
A-7
A-8 Sure Cuts A Lot
A-8
