--- POWER ---
To indicate the power status.
[ Arrow Keys ]
1. To move the tool carriage position on X or Y axis.
2. To select functions or change values of settings.
[ ENTER ]
1. The displayed parameters will be saved automatically.
2. To set a new origin at the present tool carriage position.
In “offline” mode, moving the tool carriage to desired
position by [Arrow Keys], then press [ENTER] key to set a
new origin. While moving with the parameters of XY-axes
displayed, press [MISC] key will enable fine-tune
movement; press [MISC] key again to disable the function.
[ PAUSE/RESUME ]
To temporarily halt the cutting process.
To resume the process by press [Pause/Resume] key again.
[ ONLINE/OFFLINE ]
1. To switch between online mode and offline mode.
2. To stop the cutting job or abort the change of setting.
Once press this key, the cutting job will be terminated
immediately and cannot be resumed.
[ OFFSET ]
To set or modify the distance between the blade tip and the
center axis. Through left or right arrow keys, users can select
the blade used (Red, Green, Yellow, Blue, Black capped
blade or Pen) then adjust the offset values after pressing
Enter if necessary
0.000~1.000mm
0.275mm
[ FORCE ]
C Force
To set or modify the value of cutting blade force.
When the cutting force exceeds 450g, the maximum cutting
speed would be 15 cm/sec and the cutting quality would be
Small Letter Mode and while the cutting force is 300g-449g,
the maximum cutting speed would be 30 cm/sec and the
cutting quality would be Fine Mode.
5~600gram;
5 gram/per step
80 gram
P Force
To set or modify the value of pen force.
When the pen force exceeds 450g, the maximum pen speed
would be 15 cm/sec and the pen quality would be Small
Letter Mode and while the cutting force is 300g-449g, the
maximum pen speed would be 30 cm/sec and the cutting
quality would be Fine Mode.
5~600gram;
5 gram/per step
80 gram
[ SPEED ]
C Speed
To set or modify cutting blade speed at horizontal moving.
When the cutting speed exceeds 72 cm/sec, the cutting
quality would be Normal Mode.
3~153cm/sec;
3cm/sec per step
72cm/sec
P Speed
To set or modify pen speed at horizontal moving.
3~153cm/sec;
3cm/sec per step
72cm/sec
Up Speed
To set or modify both cutting blade and pen speed at vertical
moving.
3~153cm/sec;
3cm/sec per step
72cm/sec
AAS Speed
To set or modify AAS detecting speed.
High, Medium,
Low
Medium
