GE LOGIQ 5 Service Manual

GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
4-38 Section 4-8 - Mechanical Function Checks
4-8-2-6 Bumper Set
• Check if the bumper set is fastened so that it won't move.
• Check if the bumper set can not be removed easily.
4-8-2-7 Air filter set
Check if the air filter set is placed deep inside.
Figure 4-38 Bumper Set
Figure 4-39 Air filter set
