GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
Chapter 5 Components and Functions 5 - 21
5-7-2-2 Cable Connection - Color Printer (cont’d)
Connect the cables listed below between the Color Printer and the console.
Figure 5-18 Cable Connection between Color Printer and Console
Rear Panel of UP-2950 SERIES
COLOR VIDEO PRINTER
SYNC S- VIDEO VIDEO
SYNC S- VIDEO VIDEO
ON
OFF
~AC IN
RS232C CABLE
POWER CABLE
Rear Panel of UP-2950 SERIES
COLOR VIDEO PRINTER
BNC CABLE for VIDEO SIGNAL
(supplied with color video printer)
SYNCS-VIDEO VI DEO
SYNCS-VIDEO VIDEO
ON
OFF
~AC IN
Rear Panel of JUPITER
DIP SW FUNCTION TABLE
DIP SW
