GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
5 - 22 Section 5-6 - Top Console
5-7-2-2 Cable Connection - Color Printer (cont’d)
Connect USB cable listed below between the SONY UP-D21MD Color Printer and the console.
Figure 5-19 USB Cable Connection between Color Printer and Console
POWER CABLE
Rear Panel of JUPITER
SYNC S-VIDEO VID EO
SYNC S-VIDEO VID EO
USB cable
SONY UP-D21MD
