GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 1 LOGIQ™ 5 SERVICE MANUAL
Chapter 5 Components and Functions 5 - 29
5-8-4-2 Safety
• Circuit Breaker
• Electrical Isolation
The rear-panel's Insite (modem) interface is electrically isolated from the system's internal circuit.
The isolator's dielectric strength should be 500VAC RMS or higher within 1 minute (in compliance
with IEC60601-1-1).
5-8-4-3 Camera (Printer) Remote Control Interface
The Rear-panel has two remote control interface terminals for B/W and color printers.
Table 5-15 Circuit Breaker Specification
Assembly
Power Voltage Rating
(V)
Peripheral Current
Rating (A)
Trip Time Reset Time
REAR CONN
110 5.0
1 hour max. @ 5.4A, 25
degreeC
60 seconds
REAR CONN 220V
220 3.0
1 hour max. @ 3.5A, 25
degreeC
180 seconds
Table 5-16 Camera (Printer) Remote Control Interface Specifications
Level (V) Active Polarity Retention Time
Color camera (shutter) control
H:2.0/L:0.8 L 60 msec
B/W camera (printer) control
H:2.0/L:1.0 L 100 msec
