GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
8-98 Section 8-7 - PCB Boards
8-7-4-4 Removal Procedure (cont’d)
9.) Perform the following functional tests. If all are successful, include the debrief script provided below.
8-7-4-5 Mounting Procedure
Install the new parts in the reverse order of removal.
Table 8-46 Functional Tests
Service Manual
Section Functional Test / Diagnostic Test Debrief Script
Section 4-3-1
Power On/Boot Up
“Service Manual, Direction
2300000, Rev 1+, Section 8-7-4. Equipment
passed all required tests and is ready for use. “
Section 4-3-2
Power Off / Shutdown
Section 4-9
Board Function Checks
Section 4-3-4
System B/M-Mode Checks
Section 4-3-5
System CFM and PWD Checks
Section 10-5-2
Functional Checks (See Also Chapter 4)
Section 10-6
Using a Phantom
