IRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-105
8-8-1-5 BEP Cable Connection with Console( In case of change BEP 1 into BEP2 or BEP3) (cont’d)
6.) Connect LI, LO, MI, ETHERNET Connector to Sound/LAN Port on BEP.
7.) Connect CON17 Connector to BEP.
8.) Check the CON 17 cable is arranged without short before connecting.
Figure 1-105 Connecting Cables
Figure 1-106 Connecting CON17 cables
Ethernet Cable
MI (MIC : Red) cable
LO (Line Out : Green) Cable
LI (Line In : Blue) Cable
CON 17 cable
