GE LOGIQ 5 Service Manual
4
of 1
of 1 rating
452 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
GE M
EDICAL
S
YSTEMS
D
IRECTION
2300000, R
EVISION
2
LOGIQ™5 S
ERVICE
M
ANUAL
8-106
Section 8-8 - PC Block
8-8-1-5 BEP Cable Connection with Console( In case of change BEP 1 into BEP2 or
BEP3)
(cont’d)
9.)
Connect CON21 Connector to BEP.
10.)
Connection COM1 Connect
or to S
erial Port on BEP.
NOTE:
COM1 Cable Connect to
Motherboard Serial Port (
D-SUB 9 Pin Male )
Figure 1-107 CON21 cab
le connection
Figure 1-108 COM1 cab
le connection
CON 21
Cable
COM1 cable
301
303
