4.6 S5 TESTING 4 PROGRAMMING
4
4.6.5 SWITCH INPUTS SIMULATION
Figure 4–38: SETPOINTS PAGE 5 – TESTING / SWITCH INPUTS SIMULATION
•
SIMULATION
: Enter
ON
to switch from actual switch inputs to the programmed simulated switches. Set this
setpoint
OFF
after simulation is complete.
•
SIMULATION ENABLED FOR
: Select the desired length of time that simulation will be enabled. When the
programmed time has elapsed, switch input simulation will turn off. If
UNLIMITED
is selected, the simulated
switch inputs will be used until simulation is turned off via the simulation on/off message or via the serial
port or until control power is removed from the PQM.
•
SWITCH INPUT A / B / C / D
: Enter the switch input status (open or closed) to be simulated.
4.6.6 FACTORY USE ONLY
•
SERVICE PASSCODE
: These messages are for access by GE Power Management personnel only for
testing and service.
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
]] SETPOINTS
]] S5 TESTING
] SWITCH INPUTS
] SIMULATION
SIMULATION:
OFF
SIMULATION ENABLED
FOR: 15 min
SWITCH INPUT A:
OPEN
]] SETPOINTS
]] S1 PQM SETUP
SETPOINT
Range: OFF, ON
Range: 5 to 300, UNLIMITED
Step: 5 min
SWITCH INPUT B:
OPEN
SWITCH INPUT C:
OPEN
SWITCH INPUT D:
OPEN
Range: OPEN, CLOSED
Range: OPEN, CLOSED
Range: OPEN, CLOSED
Range: OPEN, CLOSED
] FACTORY
] USE ONLY
] END OF PAGE S5
]
SERVICE PASSCODE:
0
