GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 7-15
7 MODBUS COMMUNICATIONS 7.3 MODBUS MEMORY MAP
7
7.3.3 PQM MEMORY MAP
Table 7–10: PQM MEMORY MAP (Sheet 1 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Product Information (Input Registers) Addresses - 0000-007F
PRODUCT
ID
0000 Product Device Code --- --- --- F1 65
0001 Hardware Version Code --- --- --- F5 current version
0002 Main Software Version Code --- --- --- F1 current version
0003 Modification File Number 1 --- --- --- F1 mod. file number 1
0004 Boot Software Version Code --- --- --- F1 current version
0005 Supervisor Processor Version Code --- --- --- F1 current version
0006 Product options --- --- --- F100 from order code
0007 Modification File Number 2 --- --- --- F1 mod. file number 2
0008 Modification File Number 3 --- --- --- F1 mod. file number 3
0009 Modification File Number 4 --- --- --- F1 mod. file number 4
000A Modification File Number 5 --- --- --- F1 mod. file number 5
000B Reserved
to
↓
001F Reserved
0020 Serial Number Character 1 and 2 --- --- ASCII F10 1
st
, 2
nd
char.
0021 Serial Number Character 3 and 4 --- --- ASCII F10 3
rd
, 4
th
char.
0022 Serial Number Character 5 and 6 --- --- ASCII F10 5
th
, 6
th
char
0023 Serial Number Character 7 and 8 --- --- ASCII F10 7
th
, 8
th
char.
0024 Reserved
to
↓
002F Reserved
0030 Manufacture Month/Day --- --- --- F24 manf. month/day
0031 Manufacture Year --- --- --- F25 manufacture year
0032 Calibration Month/Day --- --- --- F24 cal. month/day
0033 Calibration Year --- --- --- F25 calibration year
0034 Reserved
0035 Reserved
to
↓
007F Reserved
Commands (Holding Registers) Addresses - 0080-00EF
COMMANDS 0080 Command Function Code 5 --- --- F1 5
0081 Command Operation Code 1 to 35 1 --- F7 0
0082 Command Data 1 0 to 65535 1 --- * 0
0083 Command Data 2 0 to 65535 1 --- F31 0
0084 Command Data 3 0 to 65535 1 --- F8 0
0085 Command Data 4 0 to 65535 1 --- F8 0
0086 Command Data 5 0 to 65535 1 --- F8 0
0087 Command Data 6 0 to 65535 1 --- F8 0
0088 Command Data 7 0 to 65535 1 --- F8 0
0089 Command Data 8 0 to 65535 1 --- F8 0
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
