2-2 PQM Power Quality Meter GE Power Management
2.1 PHYSICAL 2 INSTALLATION
2
2.1.2 PRODUCT IDENTIFICATION
Product attributes vary according to the configuration and options selected on the customer order. Before
applying power to the PQM, examine the label on the back and ensure the correct options are installed.
The following section explains the information included on the label shown below:
Figure 2–2: PRODUCT LABEL
1.
MODEL NO
: Shows the PQM configuration. The model number for a basic panel mount PQM is “PQM”.
The model number for a basic chassis mount PQM is “PQM\ND”. T20, C, and A appear in the model num-
ber only if the Transducer, Control, or Power Analysis options are installed.
2.
SUPPLY VOLTAGE
: Indicates the power supply input configuration installed in the PQM. The PQM shown
in this example can accept any AC 50/60Hz voltage from 70 to 265 V AC or DC voltage from 90 to 300 V
DC.
3.
TAG#
: An optional identification number specified by the customer.
4.
MOD#
: Used if unique features have been installed for special customer orders. This number should be
available when contacting GE Power Management for technical support.
5.
VERSION
: An internal GE Power Management number that should be available when contacting us for
technical support.
6.
SERIAL NO
: Indicates the serial number for the PQM in numeric and barcode formats that should be avail-
able when contacting GE Power Management for technical support.
20
19
18
17
16
15
141312
11
10
9
MAXIMUM CONTACT RATING
250 VAC 10A RESISTIVE
1/4HP 250VAC 1/2HP 125VAC
PQM
MODEL NO.:
CONTROL VOLTAGE: SERIAL No.:
VERSION:
CUSTOMER TAG No.: 1234-567-89
90-300VDC 20VA
70-265VAC 50/60HZ 20VA
340.000
C6560001
PQM-T20-C-A
MADE IN
CANADA
g
