4.5 S4 ALARMS/CONTROL 4 PROGRAMMING
4
4.5 S4 ALARMS/CONTROL 4.5.1 CURRENT/VOLTAGE ALARMS
]] SETPOINTS
]] S4 ALARMS/CONTROL
]] SETPOINTS
]] S5 TESTING
SETPOINT
DETECT I/V ALARMS
USING PERCENTAGE: NO
PHASE UNDERCURRENT
RELAY: OFF
Range: NO, YES
PHASE UNDERCURRENT
LEVEL < 100 A
PHASE UNDERCURRENT
DELAY: 10.0 s
DETECT UNDERCURRENT
WHEN 0A: NO
PHASE OVERCURRENT
RELAY: OFF
PHASE OVERCURRENT
LEVEL > 100 A
PHASE OVERCURRENT
DELAY: 10.0 s
PHASE OVERCURRENT
ACTIVATION: AVERAGE
NEUTRAL OVERCURRENT
RELAY: OFF
NEUTRAL OVERCURRENT
LEVEL > 100 A
NEUTRAL OVERCURRENT
DELAY: 10.0 s
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 1 to 12000; Step 1 A
Range: ALARM, AUX1, AUX2,
AUX3, OFF
] CURRENT/VOLTAGE
]
Range: NO, YES
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 1 to 12000; Step 1 A
Range: AVERAGE, MAXIMUM
CONTINUED ON
NEXT PAGE
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: 1 to 12000; Step 1 A
Range: 0.5 to 600.0 s; Step 0.5 s
Range: ALARM, AUX1, AUX2,
AUX3, OFF
MESSAGE
MESSAGE
MESSAGE
