GE Power Quality Meter Series

5-12 PQM Power Quality Meter GE Power Management
5.2 A1 METERING 5 MONITORING
5
5.2.5 ENERGY
Figure 5–7: ACTUAL VALUES PAGE 1 – METERING / ENERGY
]] ACTUAL VALUES
]] A1 METERING
] ENERGY
]
3 Φ
ΦΦ
Φ POS REAL ENERGY
= 32745 kWh
3 Φ
ΦΦ
Φ NEG REAL ENERGY
= 32745 kWh
3 Φ
ΦΦ
Φ POS REACT ENERGY
= 32745 kvarh
3 Φ
ΦΦ
Φ NEG REACT ENERGY
= 32745 kvarh
]] ACTUAL VALUES
]] A2 STATUS
ACTUAL
3 Φ
ΦΦ
Φ APPARENT ENERGY
= 32745 kVAh
REAL ENERGY LAST 24h
= 1245 kWh
REAL ENERGY COST =
$12575.34
REAL ENERGY COST =
$125.01 / DAY
MESSAGE
MESSAGE
MESSAGE
TARIFF PERIOD 1 COST
$0.00
TARIFF PERIOD 2 COST
$0.00
TARIFF PERIOD 3 COST
$0.00
TARIFF PERIOD 1 NET
ENERGY: 0 kWh
TARIFF PERIOD 2 NET
ENERGY: 0 kWh
TARIFF PERIOD 3 NET
ENERGY: 0 kWh
TIME OF LAST RESET:
12:00:00am 01/01/95
