GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 8-9
8 DNP COMMUNICATIONS 8.1 DNP 3.0 PROTOCOL
8
8.1.7 POINT LIST FOR ANALOG INPUT/OUTPUT CHANGE
In the following table, the entry in the “Format” column indicates that the format of the associated data point
can be determined by looking up the entry in Table 7–11: MEMORY MAP DATA FORMATS on page 7–55. For
example, an “F1” format is described in that table as a (16-bit) unsigned value without any decimal places.
Therefore, the value read should be interpreted in this manner
Table 8–1: POINT LIST FOR ANALOG INPUT/OUTPUT CHANGE (Sheet 1 of 5)
POINT MOBUS
REG
DESCRIPTION UNIT / VALUE DEADBAND FORMAT
CODE
EVENT CLASS
ASSIGNED TO
1 1050 Phase CT Primary setpoint
1
amps 1 unit F1 3
2 1052 Neutral CT Primary setpoint
1
amps 1 unit F1 3
3 1054 VT Ratio setpoint
2
0.1 x ratio 1 unit F1 3
4 1055 VT Nominal Secondary Voltage
setpoint
volts 1 unit F1 3
5 - VT Nominal Phase-to-Phase
Voltage
3
(VT Ratio x Nominal Sec. adjusted
for wye or delta)
32-bit volts 1 unit F3 3
6 - VT Nominal Phase-to-Neutral
Voltage
(VT Ratio x Nominal Sec. adjusted
for wye or delta)
32-bit volts 1 unit F3 3
7 - Nominal Single-Phase VA
4
(VT Nominal Pri. x Phase CT Pri.)
32-bit VA 1 unit F3 3
8 - Nominal Three-Phase VA
(VT Nominal Pri. x Phase CT Pri. x
3)
32-bit VA 1 unit F3 3
9 0240 Phase A Current 1000ths of nominal A 20 units F1 1
10 0241 Phase B Current 1000ths of nominal 20 units F1 1
11 0242 Phase C Current 1000ths of nominal 20 units F1 1
12 0243 Average Current 1000ths of nominal 20 units F1 1
13 0244 Neutral Current 1000ths of nominal 20 units F1 1
14 0245 Current Unbalance tenths of 1 percent 10 units F1 2
15 0280 Voltage Van 1000ths of nominal V 20 units F3 1
16 0282 Voltage Vbn 1000ths of nominal V 20 units F3 1
17 0284 Voltage Vcn 1000ths of nominal V 20 units F3 1
18 0286 Average Phase Voltage 1000ths of nominal V 20 units F3 1
19 0288 Voltage Vab 1000ths of nominal V 20 units F3 1
20 028A Voltage Vbc 1000ths of nominal V 20 units F3 1
21 028C Voltage Vca 1000ths of nominal V 20 units F3 1
22 028E Average Line Voltage 1000ths of nominal 20 units F3 1
23 0290 Voltage Unbalance 0.1 x % 10 units F1 2
24 02F0 3 Phase Real Power 1000ths of nominal VA 20 units F4 2
25 02F2 3 Phase Reactive Power 1000ths of nominal VA 20 units F4 2
26 02F4 3 Phase Apparent Power 1000ths of nominal VA 20 units F3 2
see footnote explanations at the end of the table
