GE Power Quality Meter Series User Manual

8-10 PQM Power Quality Meter GE Power Management
8.1 DNP 3.0 PROTOCOL 8 DNP COMMUNICATIONS
8
27 02F6 3 Phase Power Factor % 5 units F2 2
28 02F7 Phase A Real Power 1000ths of nominal 20 units F4 3
29 02F9 Phase A Reactive Power 1000ths of nominal 20 units F4 3
30 02FB Phase A Apparent Power 1000ths of nominal 20 units F3 3
31 02FD Phase A Power Factor % 5 units F2 3
32 02FE Phase B Real Power 1000ths of nominal 20 units F4 3
33 0300 Phase B Reactive Power 1000ths of nominal 20 units F4 3
34 0302 Phase B Apparent Power 1000ths of nominal 20 units F3 3
35 0304 Phase B Power Factor % 5 units F2 3
36 0305 Phase C Real Power 1000ths of nominal 20 units F4 3
37 0307 Phase C Reactive Power 1000ths of nominal 20 units F4 3
38 0309 Phase C Apparent Power 1000ths of nominal 20 units F3 3
39 030B Phase C Power Factor % 5 units F2 3
40 0400 Phase A Current Demand 1000ths of nominal 20 units F1 3
41 0401 Phase B Current Demand 1000ths of nominal 20 units F1 3
42 0402 Phase C Current Demand 1000ths of nominal 20 units F1 3
43 0403 Neutral Current Demand 1000ths of nominal 20 units F1 3
44 0404 3 Phase Real Power Demand 1000ths of nominal 20 units F4 3
45 0406 3 Phase React Power Demand 1000ths of nominal 20 units F4 3
46 0408 3 Phase Apparent Power Demand 1000ths of nominal 20 units F3 3
47 0440 Frequency 0.01x Hz .05 Hz F1 1
48 0458 Main/Alternate Analog Input Unit varies -- 32 bits 10 F3 2
49 0470 Ia Crest Factor 0.001 x CF - F1 -
50 0471 Ib Crest Factor 0.001 x CF - F1 -
51 0472 Ic Crest Factor 0.001 x CF - F1 -
52 0473 Ia Transformer Harmonic Derating
Factor
0.01 x THDF - F1 -
53 0474 Ib Transformer Harmonic Derating
Factor
0.01 x THDF - F1 -
54 0475 Ic Transformer Harmonic Derating
Factor
0.01 x THDF - F1 -
55 0478 Phase A Current THD 0.1 x % 5.0% F1 3
56 0479 Phase B Current THD 0.1 x % 5.0% F1 3
57 047A Phase C Current THD 0.1 x % 5.0% F1 3
58 047B Neutral Current THD 0.1 x % 5.0% F1 3
59 047C Voltage Van THD 0.1 x % 5.0% F1 3
60 047D Voltage Vbn THD 0.1 x % 5.0% F1 3
61 047E Voltage Vcn THD 0.1 x % 5.0% F1 3
62 047F Voltage Vab THD 0.1 x % 5.0% F1 3
Table 8–1: POINT LIST FOR ANALOG INPUT/OUTPUT CHANGE (Sheet 2 of 5)
POINT MOBUS
REG
DESCRIPTION UNIT / VALUE DEADBAND FORMAT
CODE
EVENT CLASS
ASSIGNED TO
see footnote explanations at the end of the table
