GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 4-37
4 PROGRAMMING 4.5 S4 ALARMS/CONTROL
4
Figure 4–22: SETPOINTS PAGE 4 – ALARMS/CONTROL / CURRENT/VOLTAGE
UNDERVOLTAGE
RELAY: OFF
UNDERVOLTAGE
LEVEL < 100 V
UNDERVOLTAGE
DELAY: 10.0 s
PHASES REQ'D FOR U/V
OPERATION: ANY ONE
DETECT UNDERVOLTAGE
BELOW 20V: NO
OVERVOLTAGE
RELAY: OFF
OVERVOLTAGE
LEVEL > 100 V
OVERVOLTAGE
DELAY: 10.0 s
PHASES REQ'D FOR O/V
OPERATION: ANY ONE
CURRENT UNBALANCE
RELAY: OFF
CURRENT UNBALANCE
LEVEL > 100%
CURRENT UNBALANCE
DELAY: 10.0 s
VOLTAGE UNBALANCE
RELAY: OFF
VOLTAGE UNBALANCE
LEVEL ³ 100%
VOLTAGE UNBALANCE
DELAY: 10.0 s
VOLTS PHASE REVERSAL
RELAY: OFF
VOLTS PHASE REVERSAL
DELAY: 1.0 s
Range: ALARM, AUX1, AUX2, AUX3, OFF
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 0.5 to 600.0 s; Step 0.5 s
Range: 0.5 to 600.0 s; Step 0.5 s
Range: ALARM, AUX1, AUX2,
AUX3, OFF
Range: 20 to 65000; Step 1 V
Range: 20 to 65000; Step 1 V
Range: ANY ONE, ANY TWO, ALL THREE
Range: ANY ONE, ANY TWO, ALL THREE
Range: 1 to 100%; Step 1%
Range: 1 to 100%; Step 1%
Range: NO, YES
Range: ALARM, AUX1, AUX2,
AUX3, OFF
CONTINUED FROM
PREVIOUS PAGE
These setpoints are not visible if VT WIRING
is set to SINGLE PHASE DIRECT
