7-16 PQM Power Quality Meter GE Power Management
7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
COMMANDS
continued
008A Command Data 9 0 to 65535 1 --- F8 0
008B Command Data 10 0 to 65535 1 --- F8 0
008C Command Data 11 0 to 65535 1 --- F8 0
008D Reserved
to
↓
00EF Reserved
Broadcast Command (Holding Registers) Addresses - 00F0-00FF
BROADCAST
COMMAND
00F0 Time Hours/Minutes 0 to 65535 1 hr/min F22 N/A
00F1 Time Seconds 0 to 59999 1 ms F23 N/A
00F2 Date Month/Day 0 to 65535 1 --- F24 N/A
00F3 Date Year 0 to 59999 1 --- F25 N/A
00F4 Reserved
to
↓
00FF Reserved
User Definable Register (Input Registers) Addresses - 0100-017F
USER
DEFINABLE
REGISTERS
0100 User Definable Data 0000 --- --- --- --- ---
0101 User Definable Data 0001 --- --- --- --- ---
0102 User Definable Data 0002 --- --- --- --- ---
0103 User Definable Data 0003 --- --- --- --- ---
0104 User Definable Data 0004 --- --- --- --- ---
0105 User Definable Data 0005 --- --- --- --- ---
0106 User Definable Data 0006 --- --- --- --- ---
0107 User Definable Data 0007 --- --- --- --- ---
0108 User Definable Data 0008 --- --- --- --- ---
0109 User Definable Data 0009 --- --- --- --- ---
010A User Definable Data 000A --- --- --- --- ---
010B User Definable Data 000B --- --- --- --- ---
to
↓↓↓↓↓↓
0177 User Definable Data 0077 --- --- --- --- ---
0178 Reserved
to
↓
017F Reserved
User Definable Register Index (Holding Registers) Addresses - 0180-01FF
USER
DEFINABLE
REGISTER
INDEX
0180 Register address for User Data 0000 ***** 1 --- F1 0
0181 Register address for User Data 0001 ***** 1 --- F1 0
0182 Register address for User Data 0002 ***** 1 --- F1 0
0183 Register address for User Data 0003 ***** 1 --- F1 0
0184 Register address for User Data 0004 ***** 1 --- F1 0
0185 Register address for User Data 0005 ***** 1 --- F1 0
0186 Register address for User Data 0006 ***** 1 --- F1 0
0187 Register address for User Data 0007 ***** 1 --- F1 0
0188 Register address for User Data 0008 ***** 1 --- F1 0
0189 Register address for User Data 0009 ***** 1 --- F1 0
018A Register address for User Data 000A ***** 1 --- F1 0
Table 7–10: PQM MEMORY MAP (Sheet 2 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
