GE Power Quality Meter Series User Manual

GE Power Management PQM Power Quality Meter 5-29
5 MONITORING 5.4 A3 POWER ANALYSIS
5
Negative Real Power Demand Alarm/Control Dropout 3Φ –kW DMD ↓
Positive Reactive Power Demand Alarm/Control Pickup 3Φ +kvar DMD ↑
Positive Reactive Power Demand Alarm/Control Dropout 3Φ +kvar DMD ↓
Negative Reactive Power Demand Alarm/Control Pickup 3Φ –kvar DMD ↑
Negative Reactive Power Demand Alarm/Control Dropout 3Φ –kvar DMD ↓
Apparent Power Demand Alarm/Control Pickup 3Φ kVA DEMAND ↑
Apparent Power Demand Alarm/Control Dropout 3Φ kVA DEMAND ↓
Phase A Current Demand Alarm/Control Pickup Ia DEMAND ↑
Phase A Current Demand Alarm/Control Dropout Ia DEMAND ↓
Phase B Current Demand Alarm/Control Pickup Ib DEMAND ↑
Phase B Current Demand Alarm/Control Dropout Ib DEMAND ↓
Phase C Current Demand Alarm/Control Pickup Ic DEMAND ↑
Phase C Current Demand Alarm/Control Dropout Ic DEMAND ↓
Neutral Current Demand Alarm/Control Pickup In DEMAND ↑
Neutral Current Demand Alarm/Control Dropout In DEMAND ↓
Switch Input A Alarm/Control Pickup SW A ACTIVE ↑
Switch Input A Alarm/Control Dropout SW A ACTIVE ↓
Switch Input B Alarm/Control Pickup SW B ACTIVE ↑
Switch Input B Alarm/Control Dropout SW B ACTIVE ↓
Switch Input C Alarm/Control Pickup SW C ACTIVE ↑
Switch Input C Alarm/Control Dropout SW C ACTIVE ↓
Switch Input D Alarm/Control Pickup SW D ACTIVE ↑
Switch Input D Alarm/Control Dropout SW D ACTIVE ↓
Pulse Input 1 Alarm/Control Pickup PULSE IN 1 ↑
Pulse Input 1 Alarm/Control Dropout PULSE IN 1 ↓
Pulse Input 2 Alarm/Control Pickup PULSE IN 2 ↑
Pulse Input 2 Alarm/Control Dropout PULSE IN 2 ↓
Pulse Input 3 Alarm/Control Pickup PULSE IN 3 ↑
Pulse Input 3 Alarm/Control Dropout PULSE IN 3 ↓
Pulse Input 4 Alarm/Control Pickup PULSE IN 4 ↑
Pulse Input 4 Alarm/Control Dropout PULSE IN 4 ↓
Totalized Pulses Alarm/Control Pickup PULSE TOTAL ↑
Totalized Pulses Alarm/Control Dropout PULSE TOTAL ↓
Current THD Alarm/Control Pickup CURRENT THD ↑
Current THD Alarm/Control Dropout CURRENT THD ↓
Voltage THD Alarm/Control Pickup VOLTAGE THD ↑
Voltage THD Alarm/Control Dropout VOLTAGE THD ↓
Main Analog Input Alarm/Control Pickup AN INPUT MAIN ↑
Main Analog Input Alarm/Control Dropout AN INPUT MAIN ↓
Table 5–1: LIST OF POSSIBLE EVENTS (Sheet 2 of 3)
EVENT NAME DISPLAYED EVENT NAME
