7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
VOLTAGE
continued
0296 Voltage Vcn - Minimum (Low) --- --- V F3 N/A
0297 Voltage Vab - Minimum (high) --- --- V F3 N/A
0298 Voltage Vab - Minimum (Low) --- --- V F3 N/A
0299 Voltage Vbc - Minimum (high) --- --- V F3 N/A
029A Voltage Vbc - Minimum (Low) --- --- V F3 N/A
029B Voltage Vca - Minimum (high) --- --- V F3 N/A
029C Voltage Vca - Minimum (Low) --- --- V F3 N/A
029D Voltage Unbalance - Minimum --- --- 0.1 x% F1 N/A
029E Voltage Van - Maximum (high) --- --- V F3 N/A
029F Voltage Van - Maximum (Low) --- --- V F3 N/A
02A0 Voltage Vbn - Maximum (high) --- --- V F3 N/A
02A1 Voltage Vbn - Maximum (Low) --- --- V F3 N/A
02A2 Voltage Vcn - Maximum (high) --- --- V F3 N/A
02A3 Voltage Vcn - Maximum (Low) --- --- V F3 N/A
02A4 Voltage Vab - Maximum (high) --- --- V F3 N/A
02A5 Voltage Vab - Maximum (Low) --- --- V F3 N/A
02A6 Voltage Vbc - Maximum (high) --- --- V F3 N/A
02A7 Voltage Vbc - Maximum (Low) --- --- V F3 N/A
02A8 Voltage Vca - Maximum (high) --- --- V F3 N/A
02A9 Voltage Vca - Maximum (Low) --- --- V F3 N/A
02AA Voltage Unbalance - Maximum --- --- 0.1 x% F1 N/A
02AB Time - Hour/Minutes of Voltage Van Min --- --- --- F22 N/A
02AC Time - Seconds of Voltage Van Min --- --- --- F23 N/A
02AD Date - Month/Day of Voltage Van Min --- --- --- F24 N/A
02AE Date - Year of Voltage Van Min --- --- --- F25 N/A
02AF Time - Hour/Minutes of Voltage Vbn Min --- --- --- F22 N/A
02B0 Time - Seconds of Voltage Vbn Min --- --- --- F23 N/A
02B1 Date - Month/Day of Voltage Vbn Min --- --- --- F24 N/A
02B2 Date - Year of Voltage Vbn Min --- --- --- F25 N/A
02B3 Time - Hour/Minutes of Voltage Vcn Min --- --- --- F22 N/A
02B4 Time - Seconds of Voltage Vcn Min --- --- --- F23 N/A
02B5 Date - Month/Day of Voltage Vcn Min --- --- --- F24 N/A
02B6 Date - Year of Voltage Vcn Min --- --- --- F25 N/A
02B7 Time - Hour/Minutes of Voltage Vab Min --- --- --- F22 N/A
02B8 Time - Seconds of Voltage Vab Min --- --- --- F23 N/A
02B9 Date - Month/Day of Voltage Vab Min --- --- --- F24 N/A
02BA Date - Year of Voltage Vab Min --- --- --- F25 N/A
02BB Time - Hour/Minutes of Voltage Vbc Min --- --- --- F22 N/A
02BC Time - Seconds of Voltage Vbc Min --- --- --- F23 N/A
02BD Date - Month/Day of Voltage Vbc Min --- --- --- F24 N/A
02BE Date - Year of Voltage Vbc Min --- --- --- F25 N/A
02BF Time - Hour/Minutes of Voltage Vca Min --- --- --- F22 N/A
02C0 Time - Seconds of Voltage Vca Min --- --- --- F23 N/A
02C1 Date - Month/Day of Voltage Vca Min --- --- --- F24 N/A
Table 7–10: PQM MEMORY MAP (Sheet 6 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
