7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
02EE Reserved
02EF Reserved
POWER 02F0 3 Phase Real Power (high) --- --- 0.01 x kW F4 N/A
02F1 3 Phase Real Power (low) --- --- 0.01 x kW F4 N/A
02F2 3 Phase Reactive Power (high) --- --- 0.01 x kvar F4 N/A
02F3 3 Phase Reactive Power (low) --- --- 0.01 x kvar F4 N/A
02F4 3 Phase Apparent Power (high) --- --- 0.01 x kVA F3 N/A
02F5 3 Phase Apparent Power (low) --- --- 0.01 x kVA F3 N/A
02F6 3 Phase Power Factor --- --- 0.01 x PF F2 N/A
02F7 Phase A Real Power (high) --- --- 0.01 x kW F4 N/A
02F8 Phase A Real Power (low) --- --- 0.01 x kW F4 N/A
02F9 Phase A Reactive Power (high) --- --- 0.01 x kvar F4 N/A
02FA Phase A Reactive Power (low) --- --- 0.01 x kvar F4 N/A
02FB Phase A Apparent Power (high) --- --- 0.01 x kVA F3 N/A
02FC Phase A Apparent Power (low) --- --- 0.01 x kVA F3 N/A
02FD Phase A Power Factor --- --- 0.01 x PF F2 N/A
02FE Phase B Real Power (high) --- --- 0.01 x kW F4 N/A
02FF Phase B Real Power (low) --- --- 0.01 x kW F4 N/A
0300 Phase B Reactive Power (high) --- --- 0.01 x kvar F4 N/A
0301 Phase B Reactive Power (low) --- --- 0.01 x kvar F4 N/A
0302 Phase B Apparent Power (high) --- --- 0.01 x kVA F3 N/A
0303 Phase B Apparent Power (low) --- --- 0.01 x kVA F3 N/A
0304 Phase B Power Factor --- --- 0.01 x PF F2 N/A
0305 Phase C Real Power (high) --- --- 0.01 x kW F4 N/A
0306 Phase C Real Power (low) --- --- 0.01 x kW F4 N/A
0307 Phase C Reactive Power (high) --- --- 0.01 x kvar F4 N/A
0308 Phase C Reactive Power (low) --- --- 0.01 x kvar F4 N/A
0309 Phase C Apparent Power (high) --- --- 0.01 x kVA F3 N/A
030A Phase C Apparent Power (low) --- --- 0.01 x kVA F3 N/A
030B Phase C Power Factor --- --- 0.01 x PF F2 N/A
030C 3 Phase Real Power - Minimum (high) --- --- 0.01 x kW F4 N/A
030D 3 Phase Real Power - Minimum (low) --- --- 0.01 x kW F4 N/A
030E 3 Phase Reactive Power - Minimum (high) --- --- 0.01 x kvar F4 N/A
030F 3 Phase Reactive Power - Minimum (low) --- --- 0.01 x kvar F4 N/A
0310 3 Phase Apparent Power - Minimum (high) --- --- 0.01 x kVA F3 N/A
0311 3 Phase Apparent Power - Minimum (low) --- --- 0.01 x kVA F3 N/A
0312 3 Phase Power Factor - Minimum --- --- 0.01 x PF F2 N/A
0313 3 Phase Real Power - Maximum (high) --- --- 0.01 x kW F4 N/A
0314 3 Phase Real Power - Maximum (low) --- --- 0.01 x kW F4 N/A
0315 3 Phase Reactive Power - Maximum (high) --- --- 0.01 x kvar F4 N/A
0316 3 Phase Reactive Power - Maximum (low) --- --- 0.01 x kvar F4 N/A
0317 3 Phase Apparent Power - Maximum (high) --- --- 0.01 x kVA F3 N/A
0318 3 Phase Apparent Power - Maximum (low) --- --- 0.01 x kVA F3 N/A
0319 3 Phase Power Factor - Maximum --- --- 0.01 x PF F2 N/A
Table 7–10: PQM MEMORY MAP (Sheet 8 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
