7-26 PQM Power Quality Meter GE Power Management
7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
POWER
continued
039E Date - Month/Day of Phase B App Pwr Max --- --- --- F24 N/A
039F Date - Year of Phase B Apparent Pwr Max --- --- --- F25 N/A
03A0 Time - Hour/Minutes of Phase B PF Max --- --- --- F22 N/A
03A1 Time - Seconds of Phase B PF Max --- --- --- F23 N/A
03A2 Date - Month/Day of Phase B PF Max --- --- --- F24 N/A
03A3 Date - Year of Phase B Power Factor Max --- --- --- F25 N/A
03A4 Time - Hour/Min of Phase C Real Pwr Min --- --- --- F22 N/A
03A5 Time - Seconds of Phase C Real Pwr Min --- --- --- F23 N/A
03A6 Date - Month/Day of Phase C Real Pwr Min --- --- --- F24 N/A
03A7 Date - Year of Phase C Real Power Min --- --- --- F25 N/A
03A8 Time - Hour/Min of Phase C React Pwr Min --- --- --- F22 N/A
03A9 Time - Seconds of Phase C React Pwr Min --- --- --- F23 N/A
03AA Date - Mnth/Day of Phase C React Pwr Min --- --- --- F24 N/A
03AB Date - Year of Phase C Reactive Pwr Min --- --- --- F25 N/A
03AC Time - Hour/Min of Phase C App Pwr Min --- --- --- F22 N/A
03AD Time - Seconds of Phase C App Pwr Min --- --- --- F23 N/A
03AE Date - Month/Day of Phase C App Pwr Min --- --- --- F24 N/A
03AF Date - Year of Phase C Apparent Pwr Min --- --- --- F25 N/A
03B0 Time - Hour/Minutes of Phase C PF Min --- --- --- F22 N/A
03B1 Time - Seconds of Phase C PF Min --- --- --- F23 N/A
03B2 Date - Month/Day of Phase C PF Min --- --- --- F24 N/A
03B3 Date - Year of Phase C Power Factor Min --- --- --- F25 N/A
03B4 Time - Hour/Min of Phase C Real Pwr Max --- --- --- F22 N/A
03B5 Time - Seconds of Phase C Real Pwr Max --- --- --- F23 N/A
03B6 Date - Month/Day of Phase C Real Pwr Max --- --- --- F24 N/A
03B7 Date - Year of Phase C Real Power Max --- --- --- F25 N/A
03B8 Time - Hour/Min of Phase C React Pwr Max --- --- --- F22 N/A
03B9 Time - Seconds of Phase C React Pwr Max --- --- --- F23 N/A
03BA Date - Mnth/Day of Phase C React Pwr Max --- --- --- F24 N/A
03BB Date - Year of Phase C Reactive Pwr Max --- --- --- F25 N/A
03BC Time - Hour/Min of Phase C App Pwr Max --- --- --- F22 N/A
03BD Time - Seconds of Phase C App Pwr Max --- --- --- F23 N/A
03BE Date - Month/Day of Phase C App Pwr Max --- --- --- F24 N/A
03BF Date - Year of Phase C Apparent Pwr Max --- --- --- F25 N/A
03C0 Time - Hour/Minutes of Phase C PF Max --- --- --- F22 N/A
03C1 Time - Seconds of Phase C PF Max --- --- --- F23 N/A
03C2 Date - Month/Day of Phase C PF Max --- --- --- F24 N/A
03C3 Date - Year of Phase C Power Factor Max --- --- --- F25 N/A
03C4 Reserved
to
↓↓↓↓↓↓
03CF Reserved
Table 7–10: PQM MEMORY MAP (Sheet 12 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
