7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
DATA
LOGGER
LOG
NUMBERS
continued
0A61 Sa Log Number --- --- --- F110 0 = not selected
0A62 PFa Log Number --- --- --- F110 0 = not selected
0A63 Pb Log Number --- --- --- F110 0 = not selected
0A64 Qb Log Number --- --- --- F110 0 = not selected
0A65 Sb Log Number --- --- --- F110 0 = not selected
0A66 PFb Log Number --- --- --- F110 0 = not selected
0A67 Pc Log Number --- --- --- F110 0 = not selected
0A68 Qc Log Number --- --- --- F110 0 = not selected
0A69 Sc Log Number --- --- --- F110 0 = not selected
0A6A PFc Log Number --- --- --- F110 0 = not selected
0A6B P3 Log Number --- --- --- F110 0 = not selected
0A6C Q3 Log Number --- --- --- F110 0 = not selected
0A6D S3 Log Number --- --- --- F110 0 = not selected
0A6E PF3 Log Number --- --- --- F110 0 = not selected
0A6F Frequency Log Number --- --- --- F110 0 = not selected
0A70 Positive kWh Log Number --- --- --- F110 0 = not selected
0A71 Negative kWh Log Number --- --- --- F110 0 = not selected
0A72 Positive kvarh Log Number --- --- --- F110 0 = not selected
0A73 Negative kvarh Log Number --- --- --- F110 0 = not selected
0A74 kVAh Log Number --- --- --- F110 0 = not selected
0A75 Ia Demand Log Number --- --- --- F110 0 = not selected
0A76 Ib Demand Log Number --- --- --- F110 0 = not selected
0A77 Ic Demand Log Number --- --- --- F110 0 = not selected
0A78 In Demand Log Number --- --- --- F110 0 = not selected
0A79 P3 Demand Log Number --- --- --- F110 0 = not selected
0A7A Q3 Demand Log Number --- --- --- F110 0 = not selected
0A7B S3 Demand Log Number --- --- --- F110 0 = not selected
0A7C Ia THD Log Number --- --- --- F110 0 = not selected
0A7D Ib THD Log Number --- --- --- F110 0 = not selected
0A7E Ic THD Log Number --- --- --- F110 0 = not selected
0A7F In THD Log Number --- --- --- F110 0 = not selected
0A80 Van THD Log Number --- --- --- F110 0 = not selected
0A81 Vbn THD Log Number --- --- --- F110 0 = not selected
0A82 Vcn THD Log Number --- --- --- F110 0 = not selected
0A83 Vab THD Log Number --- --- --- F110 0 = not selected
0A84 Vbc THD Log Number --- --- --- F110 0 = not selected
0A85 Analog Input Log Number --- --- --- F110 0 = not selected
0A86 Reserved
to
↓ ↓ ↓ ↓ ↓ ↓
0A8F Reserved
Table 7–10: PQM MEMORY MAP (Sheet 22 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
